10W RGB full color laser light

QJ10

Working voltage input: 90-250V-50/60hz (global range) Laser color:10W full color RGBLaser brand: Chips imported from Japan's Nichia (domestic secondary assembly)Cooling method: The laser is equipped with TEC refrigeration, and the whole machine is air-cooled. Laser service life: ≥10,000 hours (test results maintained in a constant temperature environment) Laser class: Class IV Graphic scanning angle: +/-30 degrees (60 degrees)Graphic scanning speed: DT50K-galvanometer High-quality dielectric film reflectivity ≥98% Laser control signal voltage range: 0-5VLaser divergence angle: <1.6mrad (full angle) Laser spot size: size at light exit ≦3mm

No Customer Rating

€ 900 +Áfa

Product price:	€ 900 +Áfa
Total options:
Order total:

Cikkszám 00058 Kategória LASER Címke laser Márka: TZSVTAV

Leírás
További információk

Leírás

QJ10

Working voltage input: 90-250V-50/60hz (global range) Laser color:10W full color RGB

Laser brand: Chips imported from Japan’s Nichia (domestic secondary assembly)

Cooling method: The laser is equipped with TEC refrigeration, and the whole machine is air-cooled. Laser service life: ≥10,000 hours (test results maintained in a constant temperature environment) Laser class: Class IV Graphic scanning angle: +/-30 degrees (60 degrees)

Graphic scanning speed: DT50K-galvanometer High-quality dielectric film reflectivity ≥98% Laser control signal voltage range: 0-5V

Laser divergence angle: <1.6mrad (full angle) Laser spot size: size at light exit ≦3mm

Control signal mode: TTL/analog automatic switching

Modulation voltage: ≦100K

Working temperature range: -50℃~50℃ for normal use

Product size “weight”: 18cm*23cm*15cm/including handle: 24CM

single package size “weight”: 32cm*32cm*28cm/8KG
